Andamiro AVENGERS - Exploded Views and Part Identification; Detailed Parts List and Page References

6
7
5
1
2
PART NAME
SPEC
Q'TY
PAGE
BILLBOARD PART
-
1
p44
NO
BILLBOARD CABINET SIDE DECO ACRYL - L, R PART
-
2
p44
3
SMPS PART
-
1
p45
4
MAIN BOARD PART
-
1
p45
AC INPUT PART
-
1
p45
MAIN BOARD PART
-
1
p46
BIG BALL OUTLET SENSOR PART
-
1
p46
8
TICKET FND PCB PART
-
1
p46
9
CREDIT FND PCB PART
-
1
p46
10
SIDE PAYOUT GUIDE L, R PART
-
2
p47
11
MOVING PUSHER PART
-
1
p47
12
BIG BALL INLET GUIDE RAIL PART
-
1
p48
13
WHEEL COIN INLET RAIL PART
-
1
p48
14
TARGET WHEEL LIGHTING PCB PART
-
1
p48
15
BIG BALL ELEVATOR PART
-
1
p49
16
BIG BALL INLET GUIDE RAIL PART
-
1
p50
17
TARGET WHEEL PART
-
1
p50
18
SLOT WHEEL PART
-
1
p51
19
TARGET WHEEL DECO COVER PART
-
1
p51
20
TOKEN BRIDGE PART
-
1
p52
21
COIN SHOOTING RAIL PART
-
1
p52
22
TOP LED LAMP PART
-
1
p52
23
MEDAL ROLLER PART
-
1
p53
24
BIG WHEEL PART
-
1
p54
25
BIG WHEEL WIN LED PART
-
1
p55
FRONT DOOR GLASS PART
-
1
p58
26
BONUS WIN OUTLET COVER ACRYL PART
-
2
p55
27
GAUNTLET DECO PART
-
1
p55
28
CARD DISPENSER PART
-
1
p56
29
FRONT DOOR PART
-
1
p57
34
FRONT, REAR ELEVATOR HOPPER PART
-
2
p58
p57
32
BUTTON PANEL PART
-
1
35
THANOS DECO PART
-
1
p58
30
TICKET DOOR PART
-
1
p57
31
SPEAKER BOX - L, R PART
-
2
p58
33
