Andamiro AVENGERS - Exploded Views and Part Identification; SMPS Part Details; Main Board Component Details; AC Input Component Details

3)
SMPS PART
4) MAIN BOARD PART 5) AC INPUT PART
1
MAIN BOARD PCB ASS'Y
-
1
AAV10PCB001
2
AC INPUT
DAC-13H
1
AELE0FUS002
6
NOISE FILTER
RNS-2010
1
MELE0NOI009
NO
PART NAME
SPEC
Q'TY
CODE NO
4
POWER SMPS
LRS75-5
1
MELE0SMP094
5
TERMINAL BLOCK
250V 10P UL_CE
1
MELE0TEB003
2
POWER SMPS
RSP-320-24
1
MELE0SMP100
3
POWER SMPS
LRS 75-12
1
MELE0SMP093
NO
PART NAME
SPEC
Q'TY
CODE NO
1
POWER SMPS
RSP-320-12
1
MELE0SMP109
1
3
4
5
6
1
2
2
- 33 -
