Andamiro AVENGERS - Exploded Views and Part Identification; Medal Roller Component Details

23) MEDAL ROLLER PART
* CARD VERSION ONLY
7
TIMMING BELT
194XL(Wl9.5)
1
MZZZ0BEL054
8
MEDAL ROLLER CONVEYER
L:538.5 x W:100
1
MAV20RUB001
5
BEARING
F689ZZ
2
MZZZ0BEA068
6
BEARING
F606ZZ
1
MZZZ0BEA073
3
MOTOR
KGV-0060-ND3657 U2
1
MZZZ0MOT168
4
BEARING
F688ZZ
7
MZZZ0BEA076
1
PHOTO INT-1 PCB ASS'Y
ANGLE TYPE
1
AZZZ0PCB103
2
COUPLING
CR050
1
AZZZ0COP002
NO
PART NAME
SPEC
Q'TY
CODE NO
3
1
2
2
7
4
6
4
8
- 41 -
