Step 1: Screw the springs (am-4657) into the 1.0” tube
using 10-32 x.375 patch screws (am-1585) and Nylock
Nuts. (am-1063) The head of the screw should be on the
same side as the coil. The screw should be snug, but not
too tight and the spring needs to be parallel to the edges
of the tube.
Step 2: Attach clamp blocks (am-4630) using
10-32 flat head screws (am-1505) and
(am-1613). It may be helpful to use a wrench to
hold the standoff in place while inserting the
screw.
Step 3: Tie rope around the bottom standoff using a
secure not. To secure the knot it’s helpful to carefully
melt the knot and end with a lighter.
Step 4: Attach spring and clamp blocks (am-4631) to
the 1.5” tube using 10-32 flat head screws (am-1505)
and nuts.
Step 5: Attach the Bearing Plate Assembly to the top of
the 1.5” Tube using one10-32 x 0.375” Button Head
Cap Screws with thread patch (am-1588), Washers (am-
1026) and Nuts in the lower hole.
Step 6: Insert the 1.0” tube end into the 1.5” tube so
that the springs align with the top holes in the Bearing
Plates.
are sharp be careful
when uncoiling and
handling
