AndyMark Climber in a Box - Winch and Bearing Assembly; Attach Winch Plate Assembly; Install Rope Guide; Install Bearing into Plate

13 1-13-2022
Step 12: Attach the winch plate assembly to the outer stage. tube using 10-32 button head screws and nuts.
Step 13: Insert 10-32 x 2.5” screw through plate, tube and a spacers. This will help guide the rope
through the hole to the spool.
Step 15: Press a bearing into the bearing plate and attach to the plate using 10-32 button head screws and
nuts. Make s
2.0” Winch Atachment
1.5” Winch Atachment
1.5” Winch Rope Guide
2.0” Winch Rope Guide
