Anedio D2 DAC 12
Headphone Amp Maximum
Output Voltage:
4.0 Vrms (default)
5.3 Vrms (high-gain, set with internal jumpers)
Headphone Amp Maximum
Output Power
(default setting):
530 mW into 30 ohms
260 mW into 62 ohms
53 mW into 300 ohms
Headphone Amp Maximum
Output Power
(high-gain, set with internal
jumpers):
830 mW into 30 ohms
460 mW into 62 ohms
95 mW into 300 ohms
Headphone Amp Current
Output:
250 mA peak
Headphone Amp THD+N: 0.0004%, 4Vrms into 30ohms
Headphone Amp
Intermodulation Distortion:
0.0002% @ 19KHz + 20KHz, 4Vrms into 30ohms
Headphone Amp Output
Impedance:
0.035 ohm, 20-20KHz
Headphone Jack: 1/4" TRS, gold-plated
USB Streaming Mode: Asynchronous
USB Clocks: Two Independent Low-Jitter Master Clocks
USB Processor: XMOS 500 MHz real-time processor
USB Audio Operating System
Requirement:
Windows 7, Vista, XP
Apple Mac OS X
USB Audio Driver:
Thesycon driver for Windows
No driver installation for Apple OS X
Galvanic Isolation:
All digital inputs, using ultra high-speed
transformers
Power Consumption: 7 W
Dimensions (W x H x D): 9.0 x 2.8 x 10.7 inches (230 x 71 x 272 mm)
Weight: 4.6 lbs (2.1 Kg)
CE Compliance
This equipment has been found to comply with the requirements of
the EN 55022 and EN 61000-6 standards.
13 Anedio D2 DAC
Trouble Shooting
Symptoms Remedy
No power • Ensure the power cord is plugged in fully.
• Check the fuse. If blown, ensure that the outputs
are not shorted. Replace it only with 0.2A/250V
5x20mm Time-lag (slow-blo). Using an incorrect
fuse will void the warranty.
Power on but no sound • Ensure that the correct channel is selected.
• Ensure that the source component is turned on.
• Ensure that the D2 DAC is not muted, indicated
by “0” on the volume display.
• Ensure that the power amplifier is turned on.
• Ensure that the interconnects and cables are
plugged in fully and seated properly.
• If the above steps do not solve the problem,
recycle power by turning off the D2 DAC, waiting
10 seconds, and turning it back on.
No sound through USB
(Ch 1)
• Ensure that the USB cable is plugged in fully and
seated properly.
• In your media player, ensure that “Anedio USB
Audio” is selected as the device for playback.
• If the above steps do not solve the problem,
unplug the USB cable, wait 10 seconds, and plug
it back.
• When plugging the USB cable into the D2
converter, be sure to apply sufficient force so that
the plug is inserted promptly without hesitation.
Hum • Ensure that all components are connected to a
single power strip.
• If there is a cable TV or antenna connection,
ensure that the cable/antenna grounds are
galvanically isolated from the audio ground. This
may require inserting a ground isolator.
Diffused stereo imaging • Ensure that the loudspeaker phase is not
inverted.
If the problem persists, please contact Anedio via the Contact page
at www.anedio.com.
