- 16 -
C139603300_1.fm
REPLACEMENT OF THE PILOT LIGHT INJECTOR
To carry out this operation,
proceed as follows.
1 - Turn off the gas supply
tap.
2 - Pull off the knobs (A).
3 - Undo the screws (B) and
remove the control panel
(C).
4 - Unscrew the union (D).
5 - Extract the nozzle (E)
and replace it with the
one suitable for the type
of gas in use (see table
at back of manual).
6 - Retighten the union (D).
7 - Replace the control panel (C) and the knobs (A)
on completion of the operation.
DECOMMISSIONING THE APPLIANCE
Important
This operation must be carried out by
skilled operatives in compliance with the le-
gal requirements with regard to safety at
work.
Never dump non-biodegradable materials,
lubricating oils and non-metallic compo-
nents (rubber, PVC, resins, etc.) in the envi-
ronment. Dispose of them in accordance
with the relevant legal requirements.
C
A D
E
IDM-39603309900.tif
B
