anko CUBE - Page 4

4 of 15
VS-CUBE-MANUAL-REV0.1
2.0 SPECIFICATIONS
General Specications
Pump Head Series L400, A300
Tubing Class – L401, A301 ANKO Performance Class
Tubing Class – L402, A302 ANKO Premium Class
Motor Type Brushless DC
Duty Cycle Continuous
Voltage 100-240V 50/60Hz External Power Supply
Plug Type NEMA 1-15-P to DC JACK 2.5mm x 5.5mm
Max Working Pressure 25 PSI
Enclosure Powder Coated Steel - IP22 rated
Pump Head L400: Polycarbonate, IXEF | A300: Polycarbonate
Rotor L400: Stainless Steel | A300: CRS-Zinc Plated
Rollers L400: Stainless Steel | A300: Mos2 Filled Nylon
Bearings Sealed Stainless Steel
Compliance (Europe for CE Mark) EN 55014-1:2006/A12009/A2:2011
EN 55014-2:2015
Compliance (US and Canada) UL778,
ICES-003, Issue 6: 2016
FCC Part 15b Class A
Dimensions
