Chapter 3 Measurement
3-38
Table 3.7-1 Description of Peak Search Function Menu (Cont’d)
Function
Key
Menu Display Function
F8 Peak Criteria
Search performed by Peak Search and
Next Peak depends on the Peak Criteria
setting as shown in the table below.
Peak
Criteria
Peak
Search
Next
Peak
Max
Max
Search
Next
Max
Min
Min
Search
Next Min
Peak to
Peak
Peak to
Peak
Does not
perform
a search.
Default Max
The detail of Search types are as follows.
Max Search
Searches the maximum level point of the
active trace and moves the Marker.
Next Max
Searches the level of the active trace and
moves the marker to the maximum level
point which level is lower than the
current position.
Min Search
Searches the minimum level point of the
active trace and moves the marker.
Next Min
Searches the level of the active trace and
moves the marker to the minimum level
point which level is higher than the
current position.
Peak to Peak Search
Searches the level of the active trace,
moves the active marker to the
maximum level point, and moves the
maker set with Relative to of the active
marker to the minimum level point.
