SECTION
1
INTRODUCTION
Optional Components:
-
Rectifires
RP113A
Input voltage:
lOO/ll0/220
Vac
69
-
1E
-
A
Input voltage:
1OO/110/115/120/125/200/220/230/240/250
Vac
*
Gyro
-
Interface Unit
NZ2OA
Magnifier
lense
RZ702A
The following equipment can be connected to the radar. For the interface information, see Appendix
B, INSTALLATION.
Related Equipment:
*LORAN
GPS
*
Buzzer
Magnetic Compass
*
Gyro Compass Interface Unit
*
Radar
Setup
Mode
This radar can be set to the Setup mode where the front panel key configuration can be changed or the
diagnostics can be activated. It is also used during installation for setup of the radar. refer to Section
3 for details.
