Anritsu RA726UA - Appendix A - Specifications

Range resolution
Minimum detection range
Bearing accuracy
Bearing discrimination
Range accuracy
Warm up time
Environmental conditions
Temperatlrre
Humidity
Vibration
Wmd speed
DC power supply
Voltage
Power consumption
Voltage
Power consumption
AC power supply
( 2) Scanner unit
Antenna revolutions
Antenna directivity
3 ft:
4ft.
6ft:
APPENDIX A
SPECIFICATIONS
0.125 to 60 NM (RA725UA) 11 ranges
0.125 to 96 NM (RA726UA) 11 ranges
Within 20 m
Within 20 m
Within ± 1°
3.0° 3-ftantenna
2.5° 4 - ftantenna
1.8° 6 - ftantenna
Within larger of ±O.8% or 8 m
2 minutes
scanner -25° to +55° C
Display -15°
to +55° C
+35°C 95% RHmax.
Within lG(Oto3000rpm)
100 kn ots (51.4 ds)
10.8 to 40.0 Vdc
l20 W
Voltage AC power supply (option)
100/110T220 Vac switchable
200 VA mm.
24rpm ±20%
Horizontalbeamwidth 2.5° Verticalbeamwidth 22°
Sidelobes < ± 10° : -22dBmax
>=10° :-28dBmax
Horizontal beam width 1.8±° Vertical beam width 22°
Sidelobes < ±1 0° : -25dBmax
>= 10° : -3OdB max
Horizontal beam width 1.2° Vertical beam width 22°
Sidelobes
<±10° : 25 dB max.
>=10° :30 dB max. :30dBmax.
