MARKER
Pressing MARKER on the data keypad in Transmission Measurement mode ac
-
tivates a menu for the six different markers. Use the corresponding softkey to se
-
lect the desired marker. Then use the marker second level menu to turn the
markers on or off, and to edit marker parameters and values.
q
M1 — Selects the M1 marker parameter and opens the Markers second level
menu with M1 highlighted.
q
On/Off — Turns the selected marker on or off.
q
Edit — Opens the selected marker parameter for data entry. Enter the de
-
sired marker frequency using the keypad or Up/Down arrow key. Select
the
GHz, MHz, kHz,orHz softkey to accept the marker frequency input.
q
Delta (Mx-M1) — Displays delta frequency and amplitude for the selected
marker Mx (M2, M3 or M4) with respect to the M1 marker.
q
Marker To Peak — Places the selected marker at the maximum amplitude
of a trace (M1 - M4 only).
q
Marker Freq To Center — Makes the center frequency equal to the fre
-
quency of the selected marker.
q
Back — Returns to the previous menu level.
NOTE: The markers second-level menu above is identical for markers M2-M4.
q
M2 — Selects the M2 marker parameter and opens the Markers second level
menu with M2 highlighted.
q M3 — Selects the M3 marker parameter and opens the Markers second level
menu with M3 highlighted.
q
M4 — Selects the M4 marker parameter and opens the Markers second level
menu with M4 highlighted.
q
All Off — Turns off all markers.
q
More — Press to access additional marker functions:
q
M5 — Selects the M5 marker parameter and opens the M5 marker second
level menu with M5 highlighted.
q
On/Off — Turns the selected marker on or off.
q
Edit — Opens the selected marker parameter for data entry. Enter the
desired marker frequency using the keypad or Up/Down arrow key.
Select the
GHz, MHz, kHz,orHz softkey to accept the marker fre
-
quency input.
q
Marker Freq To Center — Makes the center frequency equal to the
frequency of the selected marker.
q
Peak Between M1& M2 — Places the selected marker at the frequency
with maximum amplitude value between marker M1 and M2.
q
Valley Between M1& M2 — Places the selected marker at the fre
-
quency with minimum amplitude value between marker M1 and M2.
q
Back — Returns to the previous menu level.
NOTE: If markers M1 and/or M2 are off, the Peak and Valley functions above
are executed across the entire span.
Chapter 2 Functions and Operations
2-43
