STATUS LIGHTS
Charging and load status indicator
Status light (green) Indicator Description
Charge status indicator
On Charging in progress
O No charging
Flashing rapidly Overvoltage, battery
Load status indicator
On Load connected and switched on
O Load disconnected/not connected
Flashing slowly Overload
Flashing rapidly Short circuit
Battery status indicator
Light 1 Light 2 Light 3 Light 4 Battery status
Flashing slowly On On On Undervoltage
Flashing rapidly On On On Over-discharge
FIG. 6
Battery status for increasing voltage (charging)
O O On On 12.8 V < U
bat
< 13.4 V
O O O On 13.4 V < U
bat
< 14.1 V
O O O O 14.1 V < U
bat
Battery status for decreasing voltage (discharging)
O O O On 12.8 V < U
bat
< 13.4 V
O O On On 12.4 V < U
bat
< 12.8 V
O On On On U
bat
< 12.4 V
The voltages limits apply for 12 V system at 25°C. Multiply by 2 for 24 V system.
