Output (load) On/O
When the charge controller is supplied with voltage, press the load switch (6) to connect and
disconnect the voltage to the output/load.
FIG. 7
Battery type setting
1. Switch to settings mode by pressing the button for 5 seconds until the battery status light starts ashing.
2. Select the required type of battery by pressing the button.
3. The set type of battery is saved automatically if the button is not pressed for 5 seconds, and the
status light stops ashing.
Battery type indicator
Status light 1 Status light 2 Status light 3 Battery type
O On On Sealed (standard setting)
O O On Gel (GEL)
O O O Wet cell (FLd)
BATTERY VOLTAGE LIMITS AND CHARGING TIMES
The voltages limits below apply for 12 V system at 25°C. Multiply by 2 for 24 V system.
Battery type Sealed (SEL) Gel (GEL) Wet cell (FLd)
Overvoltage, disconnection limit 16.0 V 16.0 V 16.0 V
Charging voltage, charging stopped 15.0 V 15.0 V 15.0 V
Overvoltage, reconnection limit 15.0 V 15.0 V 15.0 V
Charging voltage, equalisation charging 14.6 V — 14.8 V
Charging voltage, peak charging 14.4 V 14.2 V 14.6 V
Charging voltage, oat charging 13.8 V 13.8 V 13.8 V
Charging voltage, limit for return to peak charging 13.2 V 13.2 V 13.2 V
Undervoltage, reconnection limit 12.6 V 12.6 V 12.6 V
Undervoltage, warning stops 12.2 V 12.2 V 12.2 V
Undervoltage, warning trips 12.0 V 12.0 V 12.0 V
Undervoltage, disconnection limit 11.1 V 11.1 V 11.1 V
Undervoltage, over-discharge limit 10.6 V 10.6 V 10.6 V
Equalisation charging time 120 min — 120 min
Peak charging time 120 min 120 min 120 min
