Symbols
Indicates the drill tip exposure
Symbol with yellow background: CAUTION:
refer to accompanying documentation
Located on the Console this indicates Hand
Control activation
Located on the Console this indicates Foot
Control connector
Duty Cycle of the DRIVER Revolution per Minute
Located on the Console this indicates Forward
(Clockwise rotation when looking at handpiece
from proximal end).
Located on the Console this indicates Reverse
(Counter-Clockwise rotation when looking at the
handpiece from proximal end)
Indicates action of rotation and position for
Secure (LOCK) and Release (UNLOCK)
Located on the Console this indicates a change
of irrigation state for the Console Irrigation
System
Direction of rotation Direction of rotation
Direction of rotation for lock position
1. Console Control Touch pad: indicates a
change state (on/off) for the Console Irrigation
System
2. Irrigation Pump: Indicates irrigation tube
direction towards the irrigation source
Located on the Foot Pedal switch this indicates a
change of rotational direction for the handpiece
Located on the Foot Pedal switch this indicates
a change state (on/off) for the Console Irrigation
System
Located on the Console this indicates a change
of rotational speed rate for the Handpiece
NO NOT DISPOSE OF IN HOUSEHOLD
WASTE
Temperature Limits Sterile unless damaged or open
CE Mark (A.K.A. CE Mark [Notied body
number], Conformité Européenne)
Meaning: Device complies with applicable EEC
Directives
United States Federal Law restricts this device
to sale by or on the order of a physician or other
licensed health-care provider
Found on the Console ON/OFF
Located in the Console Irrigation Pump this
indicates a possible nger pinch point
Lock (Run) Unlock (Load)
Located on the Console Irrigation Pump these
symbols are not used by the user since the pump
is self-adjusting to the Irrigation Tube Diameter
Located on the Handpiece this indicates
position of the knurl knob to the desired location
Reference Number (A.K.A> Item Number,
Catalogue Number, Part Number)
Serial Number
Lot (A.K.A. Lot Number, Batch Number,
Batch Code)
Transmitter Interference may occur in the
vicinity of equipment marked with this symbol.
Manufacturer Type B Electrical Equipment
00/0000
Use By Date (A.K.A. Expiration Date, Expiry)
Product warranty is void if seal is damaged
or removed.
Authorized European Union Representative Single Use Only (A.K.A. Do Not Reuse)
Sterilized Using Irradiation
CAUTION: Refer to accompanying
documentation
Date of Manufacture Global Trade Item Number (GTIN)
Batch or Lot Number Expiration Date (YYMMDD)
Serial Number Quantity
Global Trade Item Number
Indicates Environmental Friendly Use Period of
50 years in China.
Indicates Environmental Friendly Use Period of
10 years in China.
Indicates Environmental Friendly Use Period
in China, this product does not contain any
hazardous substances exceeding concentration
limits.
