16. Reconnect the low pressure nitrogen hoses to the regulator
outlet tee and to tanks if previously removed. Use pipe dope
on all nitrogen connections.
17. Check the nitrogen cylinder gauge for proper minimum pres-
sure. Use the temperature correction chart on the next page to
find the true tank pressure. If the pressure is below the rec-
ommended level, the cylinder must be replaced.
16 004132
17 004134
PRESSURE REGULATOR TEST
2012-MAR-22 REV. 01 PAGE15
ANSUL Fire Suppression/Securing Systems
Operation and Maintenance – Model 100/30
