8
down for a short period in order to heat back up. During this time no fog can be produced.
The green “READY” L.E.D. on the remote will be off during this time and will light up again
when the machine is ready.
Save these instructions
DMX Connector Pin Assignment
The machine provide 3 pin XLR connector for DMX connection. Diagram below indicate pin
assignment information
Pin
Function
1
Ground
2
Data-
3
Data+
