7
Z-8 : 10 meter wired remote controller can operate the ICE machine.
Its three knobs allow the operator to customize fog machine functions
by adjusting output duration, interval and output volume.
1. Adjust the duration of each fog emission (within the range
of 1 to 15 seconds) by means of the DURATION control knob.
2. Adjust the interval between each fog emission (within the range
of 10-255 seconds) by means of the INTERVAL control knob.
3. The volume of fog produced is regulated via the OUTPUT knob. This
varies between 0 and 100% of maximum volume output.
4. Press the yellow TIMER button to activate the timer function.
5. Press the red CONTINUOUS button for continuous output.
6. When pressed, the green MANUAL button overrides all other
function controls, and activates maximum output.
Remote Control Operation
1 2
3
4 5 6
Fig. 4
Optional Remotecontrol : Z-9: Wireless remote controller
Be careful when opening and closing the cover!
