Antec P193 V3 - Page 2

1
T ABLE OF C ONTENTS
I NTRODUCTION
1.1 Case Specifications.…..………………………………………………………………………………….. 3
1.2 Diagram…………………………………………………………………….…………………………………. 3
H ARDWARE I NSTALLATION G UIDE
2.1 Setting Up….…………………………………………………………………………………………………. 4
2.2 Power Supply Installation……………………………………………………………………………… 4
2.3 CP Series Power Supply Mount…………………………………………………………………….. 5
2.4 Cable Management………………………………………………………………………………………. 5
2.5 Motherboard Installation..……………………………………………………………………………. 5
2.6 Internal 3.5” Device Installation……………………………………………………………………. 6
2.7 External 3.5” Device Installation…………………………………………………………………… 7
2.8 External 5.25” Device Installation…………………………………………………………………. 7
2.9 Internal 2.5” Device Installation…………………………………………………………………. 8
C ONNECTING THE F RONT I/O P ORTS
3.1 USB 2.0 Ports………………………………………………….……………………………………………. 9
3.2 USB 3.0 Port………………………………….……………………………………………………………. 9
3.3 AC’97 / HD Audio Ports……………………….………………………………………………………… 9
3.4 Switch and LED Connectors…………………………………………………………………………… 10
3.5 Rewiring Motherboard Header Connections………………………………………………… 10
C OOLING S YSTEM
4.1 TriCool™ Fans ………………………………………………………………………………………………. 11
4.2 Optional Fans.………………………………………………………………………………………………. 12
4.3 Washable Air Filters………………………………………..……………………………………………. 13
