10. ELECTRIC WIRING DIAGRAM
For electric start types ;
Please note the following points:
 In case the engine is mounted on rubber mounts, it is
necessary to make a separate grounding to the chassis.
 The negative (-) battery cable must be connected
directly to the engine.
 The engine switch must be in OFF position when the
engine is not running. Otherwise the voltage regulator
will be damaged and the battery will be discharged.
 The engine switch must be in ON position when the
engine is running. Otherwise the alternator will not
charge the battery and the warning lamps will not
function.
 The battery cables must not be disconnected while the
engine is running.Otherwise the voltage regulator will be
damaged.
 The temperature of the voltage regulator must not
exceed 75
o
C.
 No electric welding operation must be performed on the
chassis or equipment coupled to the engine while the
electric system is connected.
