2 - Description of the different elements
A1 Display
T1 CANCEL/RETURN button
T2 ENTER button
T3 u (move forward/down) button
T4 t (move backward/up) button
TM250HD
T1
T2
T3
A1
C3
C1
C2
C4
OUTPUTINPUT
DC input
USB
C5
C6 C7 C8
HDMI
AUDIO INPUT
COMPONENT VIDEO INPUT
YPb Pr RL
C9
C1 Power supply input (5V/4A)
C2 USB input (for programming
the TM250HD by PC)
C3 Ethernet connection RJ45
C4 RF input
C5 RF output
C6 HDMI input
C7 Component video input
C8 PC input
C9 Analog audio input
