AOC 2036Va User Manual

12
4. Input/Output Specification
4.1 Input Signal Connector
Analog connectors
Pin No. Description Pin No. Description
1 Video-Red 9 +5V
2 Video-Green 10 Ground
3 Video-Blue 11 N.C.
4 N.C. 12 DDC-Serial Data
5 Detect Cable 13 H-Sync
6 GND-R 14 V-Sync
7 GND-G 15 DDC-Serial Clock
8 GND-B
Digital connectors
Pin No. Description Pin No. Description
1
TMDS data 2－
13
TMDS data 3＋
2
TMDS data 2＋
14
＋5V Power
3 TMDS data 2/4 Shield 15 GND (return for +5V, hsync, vsync)
4
TMDS data 4－
16 Hot Plug Detect
5
TMDS data 4＋
17
TMDS data 0－
6 DDC Clock 18
TMDS data 0＋
7 DDC Data 19 TMDS data 0/5 Shield
8 Analog Vertical Sync 20
TMDS data 5－
9
TMDS data 1－
21
TMDS data 5＋
10
TMDS data 1＋
22 TMDS Clock Shield
11 TMDS data 1/3 Shield 23 TMDS Clock +
12
TMDS data 3－
24
TMDS Clock －

AOC 2036Va Specifications

General

Brand	AOC
Model	2036Va
Category	Monitor
Language	English
