AOC 2036Va - Page 15

15
Wy 0.329
Color Gamut - 72 - %
Viewing Angle (CR>5)
x axis, right(f=0°) qr 75 88 - Degree
x axis, left (f=180°) ql 75 88 -
y axis, up (f=90°) qu 70 85 -
y axis, down (f=270°) qd 70 85 -
Viewing Angle (CR>10)
x axis, right(f=0°) qr 70 85 - Degree
x axis, left (f=180°) ql 70 85 -
y axis, up (f=90°) qu 60 75 -
y axis, down (f=270°) qd 70 85 -
Crosstalk - - 1.5 %
Luminance uniformity -Angular
dependence (TCO’03)
LR - - 1.7
Color grayscale linearity Δu’v’ - 0.018 -
4.3.4 Electrical Characteristics
(1) TFT-LCD
Parameter Symbol
Values Unit
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.2 V
Power Supply Input Current
ILCD-MOSAIC - 780 935 mA
ILCD-BLACK - 950 1140 mA
Power Consumption PLCD - 3.9 4.7 Watt
Inrush current IRUSH - - 3.0 A
(2) Backlight
