AOC 20E1H

47
Panel
Model name
20E1H
Driving system
TFT Color LCD
Viewable Image Size
19.5inch, 49.4cm diagonal
Pixel pitch
0.27(H)mm x 0.27(V)mm
Video
R, G, B Analog Interface & HDMI Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Others
Horizontal scan range
30~83KHz
Horizontal scan
Size(Maximum)
433.92mm
Vertical scan range
50Hz ~ 76Hz
Vertical scan Size(Maximum)
236.34mm
Optimal preset resolution
1600x900@60Hz
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15 pin/HDMI
Power Source
100-240V~，50/60Hz，1.5A
Power Consumption
Typical (Brightness = 90,Contrast = 50)
12W
(Brightness = 100,Contrast = 100)
≤14W
Power saving
≤0.5W
Physical
Characteristics
Connector Type
D-Sub/ HDMI/ Earphone out
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°C
Non-Operating
-25° to 55°C
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 5000m(0~ 16404 ft)
Non-Operating
0~ 12192m (0~ 40000 ft )
