6.2 Electrical Block Diagram
6.2.1 Scalar Board
FLASH MEMORY
SST25LF020A
(U
4
0
2
)
Scalar TSUMU58KDT-LF-1
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(CN404)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
EEPROM
AT24C02N
(U101)
VGA_SDA
VGA_SCL
Crystal 14.31818MHz
(X401)
EEPROM
M24C04
(
U403
)
HDMI
Connector
(CN501)
EEPROM
AT24C02N
(U102)
HDMI1_SCL
HDMI1_SDA
Key Control Interface
(CN403)
