AOC 2436Vwa User Manual

20
OSD Setting
Basic and simple instruction on the control keys.
When you press the MENU button on the front control of your monitor, the On DOWN Screen Display (OSD) Main
Controls window will pop up and you can then start making adjustments to your monitor's various features. Use the
UP or DOWN keys to make your adjustments. Follow the steps below to activate the adjustment.
1) Press the MENU key to activate the OSD window.
2) Press UP or DOWN to navigate through the functions. Once the desired function is highlighted, press the MENU
key to activate it. If the function selected has a sub-menu, press UP or DOWN again to navigate through the
sub-menu functions. Once the desired function is highlighted, press MENU key to activate it.
3) Press UP or DOWN to change the settings of the selected function. Press MENU key to exit and save, select the
exit function. If you want to adjust any other function, repeat steps 2-3.
4) OSD Lock Function: To lock the OSD, press and hold the MENU key while the monitor is off and then press
power button to turn the monitor on. To unlock the OSD, press and hold the MENU key while the monitor is off and
then press power button to turn the monitor on.

AOC 2436Vwa Specifications

General

Pixel pitch	0.2715 x 0.2715 mm
Aspect ratio	16:9
Display diagonal	23.6 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	60000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	31 - 83 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
DVI-I ports quantity	0
Product color	Black
Power consumption (standby)	1 W
Power consumption (typical)	49 W

Weight and Dimensions

Depth (without stand)	206 mm
Width (without stand)	582 mm
Height (without stand)	424 mm
Weight (without stand)	5500 g
