Wall Mounting

Preparing to Install An Optional Wall Mounting Arm.

24P1/24P1U/X24P1

24E1Q

This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this

procedure. Follow these steps:

1. Remove the base.

2. Follow the manufacturer’s instructions to assemble the wall mounting arm.

3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back

of the monitor.

4. Insert the 4 screws into the holes and tighten.

5. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions

on attaching it to the wall.

Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official

department of AOC.
