AOC 60P Service Manual

50
C804
065G080547432K T
CAP CHIP 0805 0.47UF K 50V X7R
C811
065G080547432K T
CAP CHIP 0805 0.47UF K 50V X7R
C816
065G120610171J Y
CAP 1206 100PF 5% 500V NP0
709G4744 HS001
CONSUMPTIVE ASS'Y
SW001
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW004
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW005
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW003
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW002
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
E715
715G5357K03000001M
KEY PCB FR1 SS 117*10*1.6MM
C920
067G 2046812KT
CAP CS 680UF 20% 10V 8*11 3900mA GP1A6
C917
065G517K102 2T6921
CAP CER 1000PF K 500V Y5P
F902
084G 56 5 C
FUSE 5A 250V MST 5A 250V
J805
095G 90 23
JUMP WIRE - -
R915
061G 17210052T TZ
RST CFR 10R 1/4W 5%
J609
095G 90 23
JUMP WIRE - -
F904
084G 56 5 C
FUSE 5A 250V MST 5A 250V
R939
061G152M47152T SY
RST MOF 470R 5% 2W FUTABA
F901
084G 56 4 B
FUSE 4A 250V
IC903
056G 158 12
Shunt Regulator KIA431A-AT/P TO-92
C918
067G215S1024LT
EC 1000UF 20% 25V 12.5*20
J909
095G 90 23
JUMP WIRE - -
715G5361P02000001S
PWR PCB FR1 CTI>600 SS 184*145*1.6mm
J904
095G 90 23
JUMP WIRE - -
FB904
071G 55 26 H
BEAD 3.5*6.0*0.8 127R 25% BF-I35060R-796
C941
065G306K47123R
CAP Y1 470PF 10% 250V Y5P
J803
095G 90 23
JUMP WIRE - -
J902
095G 90 23
JUMP WIRE - -
FB901
071G 55 29
FERRITE BEAD
J910
095G 90 23
JUMP WIRE - -
J912
095G 90 23
JUMP WIRE - -
C942
065G 1K101 2T6921
CAP CER 100pF 1KV K Y5P
C913
067G215Y4707KT
EC 47uF 20% 50V 6.3*11mm EG
J809
095G 90 23
JUMP WIRE - -
C809
067G 4153309KT
EC 33UF 20% 100V 8*12 ED
D903
093G 6026T52T
CTIFIER DIODE FR107
C922
067G 5153314KT
EC 330UF 20% 25V EJ
J903
095G 90 23
JUMP WIRE - -
ZD901
093G 3996052T
DIODE GDZJ20B DO-35
R923
061G 60220152T TZ
RST CFR 200OHM +-5% 1/6W TZAI YUAN
