AOC 917SW - Electrical Block Diagram; Main Board

19" LCD Color Monitor AOC 917Sw
16
5.2 Electrical Block Diagram
5.2.1 Main Board
Crystal 14.318MHZ
(X401)
FLASH ROM
SST25LF020A
(U402)
Scalar TSUM1PFR
(Include ADC, OSD, MCU)
(U401)
D-Sub Connector
(
CN101
)
Panel Interface
(CN403)
Key Control Interface
(CN402)
