AOC 917SW User Manual

19" LCD Color Monitor AOC 917Sw
36
2.) W / LED, No Backlight
Check CN902 pin4, 5 = 12V
NG
OK
Check adapter or MB
Check ON/OFF signal
Check Interface board
NG
OK
Check IC801 PIN12=12V
NG
OK
Change Q808
Check IC801 PIN10, 9 have the output of square wave at short
NG
OK
Change IC801
Check Q802, Q803 PIN5, 6, 7, 8 have the output of square wave at short time.
NG
OK
Check Q801, Q804, Q811, Q812, Q802, Q803
Check the output of T801, T802
Check connecter & lamp
OK
NG
Change T801, T802

AOC 917SW Specifications

General

Pixel pitch	0.2835 x 0.2835 mm
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	255 mm
Contrast ratio (typical)	3000:1
Viewable size, horizontal	408 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	cUL, FCC, CE, TUV-S, EPA, ISO13406-2, RoHS, GOST, Pixel Fault Class II
Product color	Black
Market positioning	-
Compliance industry standards	DDC 1/2B/CI
Power requirements	110-240VAC 50/60Hz
Plug and Play	Yes
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	36 W
Package weight	4700 g

Weight and Dimensions

Depth (with stand)	204 mm
Width (with stand)	439 mm
Height (with stand)	358 mm
Weight (without stand)	3800 g
