AOC 917SW User Manual

19" LCD Color Monitor AOC 917Sw
45
052G6026 3 MESH PRINTTING PAPER
Q406 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC
ZD103 093G 39S501 T LUDZS5.6BT1G BY LRC
ZD104 093G 39S501 T LUDZS5.6BT1G BY LRC
KEPC7QK7 KEY BOARD G2834-A-X-X-1-070809
CN001 033G3802 6H WAFER 6P RIGHT ANGLE PITCH 2.0
SW005 077G610D 1 NA TACT SW+LED
SW005 077G610D 1 WB TACT SW+LED
709G2834 QM001 CONSUMPTIVE ASS'Y
Q002 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q001 057G 417 4 PMBS3904/PHILIPS-SMT(04)
R002 061G0603000 RST CHIP MAX 0R05 1/10W
R004 061G0603102 RST CHIPR 1K OHM +-5% 1/10W
R003 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R001 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R006 061G0603472 RST CHIPR 4.7K OHM +-5% 1/10W
R005 061G0603472 RST CHIPR 4.7K OHM +-5% 1/10W
SW004 077G 605 1 AL GP SMD SWITCH
SW001 077G 605 1 AL GP SMD SWITCH
SW002 077G 605 1 AL GP SMD SWITCH
SW003 077G 605 1 AL GP SMD SWITCH
ZD006 093G 64 59 SU ESD MLVS0603M04 0603
ZD007 093G 64 59 SU ESD MLVS0603M04 0603
ZD008 093G 64 59 SU ESD MLVS0603M04 0603
709G2834 QS001 CONSUMPTIVE ASS'Y
715G2834 1 KEY BOARD PCB
PWPC942SEE1 POWER BOARD G2538-3-LEG-X-1-070903
040G 45762412B CBPC LABEL
GND1 009G6005 1 GROUND TERMINAL
CN801 033G8021 2E F WAFER
CN802 033G8021 2E F WAFER
CN803 033G8021 2E F WAFER
CN804 033G8021 2E F WAFER
CN801 033G8021 2E U INVERT CONNECTOR
CN802 033G8021 2E U INVERT CONNECTOR
CN803 033G8021 2E U INVERT CONNECTOR
CN804 033G8021 2E U INVERT CONNECTOR
IC903 056G 139 3A IC PC123Y22FZ0F
IC903 056G 139 5A TCET1103G
NR901 061G 58080 WT 8 OHM NCT

AOC 917SW Specifications

General

Pixel pitch	0.2835 x 0.2835 mm
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	255 mm
Contrast ratio (typical)	3000:1
Viewable size, horizontal	408 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	cUL, FCC, CE, TUV-S, EPA, ISO13406-2, RoHS, GOST, Pixel Fault Class II
Product color	Black
Market positioning	-
Compliance industry standards	DDC 1/2B/CI
Power requirements	110-240VAC 50/60Hz
Plug and Play	Yes
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	36 W
Package weight	4700 g

Weight and Dimensions

Depth (with stand)	204 mm
Width (with stand)	439 mm
Height (with stand)	358 mm
Weight (without stand)	3800 g
