AOC 917SW User Manual

19" LCD Color Monitor AOC 917Sw
47
CN901 087G 501 37 S AC INLET ST-01DG-B2K-K
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
BD901 093G 50460510 2KBP08M 2A 800V
D907 093G3006 1 1 31DQ06FC3 NIHON INTER
CN902 095G8014 9D 57 HARNESS 9P-9P 210MM
CN902 095G8014 9X 57 WIRE HARNESS 9P(SCN)-9P(PH) 210MM
705G 193 57 01 Q901 ASS'Y
Q901 057G 667 21 STP10NK70ZFP
Q901 057G 667 22 FQPF8N80C
090G6263 1 HEAT SINK
0M1G1730 8120 SCREW
705G 193 93 01 D906 ASS'Y
D906 093G 60218 SB10100FCT
D906 093G 60267 SP10100
0M1G1730 10120 SCREW 42A9930016
Q90G6274 2 HEAT SINK
705GQ851002 OIL FOR DISAPPEAR ASS'Y
709G2538 QM001 CONSUMPTIVE ASS'Y
055G 2 ALCOHOL
055G 23524 WELDING FLUX WITHOUT PB
Q55G 100625 TIN STICK_LOW ARGENTUM
IC801 056G 379 22 IC TL494IDR SOIC-16
IC901 056G 379 71 IC TEA1530AT/N2 SO-8 NXP
Q902 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q811 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q807 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q806 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q801 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q812 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q804 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q811 057G 417 12 T KEC 2N3904S-RTK/PS
Q807 057G 417 12 T KEC 2N3904S-RTK/PS
Q806 057G 417 12 T KEC 2N3904S-RTK/PS
Q801 057G 417 12 T KEC 2N3904S-RTK/PS
Q804 057G 417 16 T MMBT2907
Q812 057G 417 16 T MMBT2907
Q802 057G 600 55 P5506 HVG SO-8
Q803 057G 600 55 P5506 HVG SO-8
Q809 057G 758 1 2N7002ESOT23 SILICONIX
Q809 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

AOC 917SW Specifications

General

Pixel pitch	0.2835 x 0.2835 mm
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	255 mm
Contrast ratio (typical)	3000:1
Viewable size, horizontal	408 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	cUL, FCC, CE, TUV-S, EPA, ISO13406-2, RoHS, GOST, Pixel Fault Class II
Product color	Black
Market positioning	-
Compliance industry standards	DDC 1/2B/CI
Power requirements	110-240VAC 50/60Hz
Plug and Play	Yes
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	36 W
Package weight	4700 g

Weight and Dimensions

Depth (with stand)	204 mm
Width (with stand)	439 mm
Height (with stand)	358 mm
Weight (without stand)	3800 g
