AOC AGON AG493UCX2 User Manual

24
OSD Setup
Exit Enter Select
OSD Setup
Timeout
H.Position
V.Position
Transparence
Break Reminder
110
100
100
100
Off
USB Off
USB Selection Auto
EnglishLanguage
Language Select the OSD language
Timeout 5-120 Adjust the OSD Timeout
H. Position 0-100 Adjust the horizontal position of OSD
V. Position 0-100 Adjust the vertical position of OSD
Transparence 0-100 Adjust the transparence of OSD
Break Reminder On /O󰀨 Break reminder if the user continuously work for more than 1hrs
USB
O󰀨/ 3.2Gen1
/ 2.0
Select the version of the USB or turn o󰀨 the USB function.
USB Selection
Auto / USB
C / USB Up
Select USB input source.
Notes:
When the USB is set to USB3.2 Gen1, the max resolution of USB C(DP Alt) interface is 5120x1440@60Hz.
When the USB is set to USB2.0 or o󰀨, the max resolution of USB C(DP Alt) interface is 5120x1440@120Hz.

AOC AGON AG493UCX2 Specifications

General

Feet color	Black/Red
Certification	ISO 9241-307
Product color	Black
Detachable stand	Yes
Market positioning	Gaming
AMD FreeSync type	FreeSync Premium Pro
NVIDIA G-SYNC type	G-SYNC Compatible
AMD FreeSync refresh rate range	48 - 165 Hz
Panel type	VA
Pixel pitch	0.2331 x 0.2331 mm
Aspect ratio	16:9, 21:9, 32:9
Pixel density	109 ppi
Backlight type	W-LED
Display surface	Matt
Display diagonal	48.8 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Adobe RGB coverage	98 %
Display resolution	5120 x 1440 pixels
Display technology	LED
Native aspect ratio	32:9
Supported video modes	1440p
NTSC coverage (typical)	100 %
Screen curvature rating	1800R
Viewable size, vertical	335.664 mm
sRGB coverage (typical)	122 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	124 cm
Viewable size, horizontal	1193.472 mm
Display brightness (typical)	400 cd/m²
High Dynamic Range (HDR) technology	DisplayHDR 400
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
Headphone connectivity	3.5 mm
USB Power Delivery up to	65 W
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
Tilt angle range	3.5 - 13.5 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Package type	Box
Package depth	553 mm
Package width	1308 mm
Package height	420 mm
Package weight	20800 g
USB cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.5 W
Power consumption (typical)	68 W
RMS rated power	5 W
Number of speakers	2
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	DisplayPort, HDMI
Exterior finish type	Textured
Harmonized System (HS) code	85285210
Sustainability certificates	WEEE

Weight and Dimensions

Depth (with stand)	308 mm
Width (with stand)	1194.4 mm
Height (with stand)	567.6 mm
Weight (with stand)	14400 g
Depth (without stand)	153.24 mm
Height (without stand)	369.4 mm
