26
4.2 Factory Preset Display Modes
STAND RESOLUTION
HORIZONTAL
FREQUENCY(kHZ)
VERTICAL
FREQUENCY(Hz)
VGA
640x480@60Hz 31.469 59.940
640x480@72Hz 37.861 72.809
640x480@75Hz 37.500 75.000
SVGA
800x600@56Hz 35.156 56.250
800x600@60Hz 37.879 60.317
800x600@72Hz 48.077 72.188
800x600@75Hz 46.875 75.000
XGA
1024x768@60Hz 48.363 60.004
1024x768@70Hz 56.476 70.069
1024x768@75Hz 60.023 75.029
SXGA
1280x1024@60Hz 63.981 60.020
1280x1024@75Hz 79.976 75.025
WXGA+ 1440x900@60Hz 55.935 59.887
WSXGA 1680x1050@60Hz 65.290 59.954
HD 1920x1080@60HZ 67.500 60.000
*** 1280x960@60HZ 60.000 60.000
IBM-MODE DOS
640x350@70Hz 31.469 70.087
720x400@70Hz 31.469 70.087
MAC MODE VGA 640x480@67Hz 35.000 66.667
MAC MODE SVGA 832x624@75Hz 49.725 74.551
MAC MODE XGA 1024x768@75Hz 60.241 74.927
Preset table for the HDMI 3D mode
