AOC e1620Sw Service Manual

20
4.3. Panel Specification
M156B1-L01 is a 15.6” wide TFT Liquid Crystal Display module with white LED(1PCS Lightbar, LED-3020 96PCS)
Backlight unit and 30pin 1ch-LVDS interface. This module supports 1366 x768 WXGA mode and can display up to
16.7M colors. The conventer module for Backlight is not built in.
4.3.1 General Feature
4.3.2 Optical Characteristics
