AOC E1670SWU User Manual

Troubleshoot
Problem & Question
Possible Solutions
Power LED Is Not ON
Make sure the power button is ON and the USB cable is properly connected
to the monitor.
No images on the screen
Is the USB cable connected properly?
Check the USB cable connection and power supply.
Is the cable connected correctly?
(Connected using the D-sub cable)
Check the DB-15 cable connection.
If the power is on, reboot the computer to see the initial screen (the login
screen), which can be seen.
If the initial screen (the login screen) appears, boot the computer in the
applicable mode (the safe mode for Windows ME/XP/2000) and then change
the frequency of the video card.
(Refer to the Setting the Optimal Resolution)
If the initial screen (the login screen) does not appear, contact the Service
Center or your dealer.
Can you see "Input Not Supported" on the screen?
You can see this message when the signal from the video card exceeds the
maximum resolution and frequency that the monitor can handle properly.
Adjust the maximum resolution and frequency that the monitor can handle
properly.
Make sure the AOC Monitor Drivers are installed.
Picture Is Fuzzy & Has
Ghosting Shadowing Problem
Adjust the Contrast and Brightness Controls.
Press to auto adjust.
Make sure you are not using an extension cable or switch box. We
recommend plugging the monitor directly to the video card output connector
on the back .
Picture Bounces, Flickers Or
Wave Pattern Appears In The
Move electrical devices that may cause electrical interference as far away
from the monitor as possible.
Use the maximum refresh rate your monitor is capable of at the resolution
your are using.
33

AOC E1670SWU Specifications

General

3D	No
HD type	WXGA
Panel type	-
Pixel pitch	0.252 x 0.252 mm
Screen shape	Flat
Response time	8 ms
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	800:1
Viewing angle, horizontal	90 °
Display brightness (typical)	180 cd/m²
Supported graphics resolutions	1366 x 768
Panel mounting interface	75 x 75 mm
Package depth	106 mm
Package width	423 mm
Package height	304 mm
Package weight	1500 g
HDMI ports quantity	0
Cables included	USB, VGA
Power consumption (standby)	- W
Power consumption (typical)	7 W
Product color	Black
Market positioning	Home

Weight and Dimensions

Depth (with stand)	142 mm
Height (with stand)	298 mm
Depth (without stand)	33 mm
Width (without stand)	371 mm
Height (without stand)	233 mm
Weight (without stand)	870 g
