AOC E2050SN Service Manual

49
H45G 87 1 25
EPE COVER
H52G1801 16006
insulating sheet
H70G21C1615 6A
e2250Swn CD MANUAL
KEPCAHB5
KEY BOARD
PLPCBB381MHD1
POWER BOARD
Q40G 58162435A
LABEL
Q45G 76 28 H A
P.E. BAGx320x210x0.04
Q52G 1185 99
BIG CARTON TAPE FOR AOC
Q52G1001207 A JY
AL FOIL
Q52G1001211 B JY
AL FOIL
Q52G6019 14
TAPE
E08907
S95G179T30NE34
FFC CABLE 30P 190mm P1.0MM
2nd source
756GHBCB A1082
MAIN BOARD-CBPCBRVA1H1
SMTCB-U402
100GARMI002W11
MCU ASS'Y-056G2233 11
CN408
033G3802 6B Y L
WAFER
CN404
033G3802 9B Y L
CONN 2.0 9P
CN403
033G801930F CH JS
FFC CONN 1.0mm 30P R/A 34mm 6.3mm
CN101
088G 35315FVCL
D-SUB CONN V/T 15P BLUE H=10.4
X401
093G 2253B J
NXS14.31818AC32F-KAB10
709G4737 HM002
COMSUPTIVE ASS'Y
H40G 45762429A
LABEL
LED001
081G 12 1F GH
LED GREEN/YELLOW GHZYG603D2-5B
CN001
095G820H 6TE10
HARNESS 6P(SANW)-6P(2008) 120
CN001
095G820H 6WE10
HARNESS 6P(SANW)-6P(2008) 120
2nd source
709G4747 HM001
COMSUPTIVE ASS'Y
GND1
009G6005 1
GND TERMINAL
U902
056G 139 3A
PC123Y22FZOF SHARP
NR901
061G 5810T
NTCR 8R 20% 3.1W SCK13084MMY501
C908
063G107K474 6S
0.47UF +-10%
C809
067G 415330 9K
EC 33UF 20% 100V ED 8*12
C907
067G 42Z68015K
EC 68UF 20% 450V 12.5*50 2000 hr
L901
073G 174 65 H2
LINE FILTER 30mH MIN
L906
073G 253191 H
IND CHOKE 1.1uH DADON
L801
073G 253214 DN
CHOKE COIL 47UH 10% LZ.CC013.G01 2.5A
T901
080GL22T 3 N3
X'FMR 490UH 7% 4UH YUVA-1656
CN901
087G 501 48 S
AC SOCKET 3PIN + 3 Hole
D902
093G 60335
DIODE SR515 5A/150V DO-201AD
D901
093G 60335
DIODE SR515 5A/150V DO-201AD
CN902
095G 825 9T518
HARNESS 9P-9P 120MM
CN902
095G 825 9W518
HARNESS 9P-9P 120MM
2nd source
0Q1G 340 8140
SCREW 4.0x8.0
CN804
311GW200A06ABX
WAFER 2.0mm 6P
705GHA57006
Q901 ASS"Y
705GHA93006
D906 ASS"Y
709G4744 HM001
CONSUMPTIVE ASS'Y
