AOC E2050SN Service Manual

52
C407
065G040210412K A
CAP CHIP 0402 100nF K 16V X7R
C406
065G040210412K A
CAP CHIP 0402 100nF K 16V X7R
C403
065G040210412K A
CAP CHIP 0402 100nF K 16V X7R
C401
065G040210412K A
CAP CHIP 0402 100nF K 16V X7R
C404
065G0402105A5K A
CAP CHIP 0402 1UF K 10V X5R
C411
065G040220031J Y
CAP 0402 20PF 5% 50V NP0
C412
065G040220031J Y
CAP 0402 20PF 5% 50V NP0
C103
065G040222031J A
CAP 0402 22PF J 50V NPO
C102
065G040222031J A
CAP 0402 22PF J 50V NPO
C106
065G040222322K T
CAP MLCC 0402 22nF K 25V X7R
C408
065G040222415K T
CAP CHIP 0402 220nF K 16V X5R
C434
065G040222415K T
CAP CHIP 0402 220nF K 16V X5R
C113
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C110
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C109
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C107
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C105
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C101
065G040247312K A
CAP 0402 47NF 10% 16V X7R
C104
065G040250931C Y
CAP 0402 5PF 0.25pF 50V NP0
C108
065G040250931C Y
CAP 0402 5PF 0.25pF 50V NP0
C111
065G040250931C Y
CAP 0402 5PF 0.25pF 50V NP0
FB402
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB401
071G 59B300 M
CHIP BEAD 0603 30ohm 25% 1000mA
FB101
071G 59K190 M
CHIP BEAD 0603 19R/500mA
FB102
071G 59K190 M
CHIP BEAD 0603 19R/500mA
FB103
071G 59K190 M
CHIP BEAD 0603 19R/500mA
D403
093G 64 42 L
DIODE LBAV70LT1G SOT-23 LRC
ZD103
093G 39GA01 T
RLZ5.6B
709G4737 HS002
COMSUPTIVE ASS'Y
E715
715G4737M02000004C
MAIN BOARD PCB
2nd source
E715
715G4737M02000004I
MAIN BOARD PCB
H52G1701 1
MESH PRINTTING_PAPER
R002
061G0603000 FF
RST CHIPR MAX0R01 1/10W FENGHUA
R004
061G06031001FF
RST CHIPR 1 KOHM +-1% 1/10W FENGHUA
R003
061G06032001FF
RST CHIP 2KOHM 1% 1/10W FENGHUA
R001
061G06032001FF
RST CHIP 2KOHM 1% 1/10W FENGHUA
Q901
057G 667941
MOSFET P0765ATF 7 650 TO-220F
HS1
090G6064 1
HEAT SINK
0M1G 930 8120
SCREW 3x8
HS3
090G6084 1 GP
HEAT SINK
D906
093G 60507
SCHOTTKY SRF1060 C0 10A 60V ITO-220AB
0M1G 930 8120
SCREW 3x8
055G 23524
WELDING FLUX WITHOUT PB
Q51G 6 4509
GLUE_RTV
Q55G 100625
TIN STICK_LOW ARGENTUM
