AOC e2060Sda Service Manual

48
T=0.9(MAX)
C11,C12,C13,C73,C7
4
0CH2A-0011A
10U F, 16 Volt, K PER, X5R(JB), 3216
R/TP, T=0.95(MAX)
C1,C103,C104,C141,
C142,C143,C144,C14
5,C146,C151,C156,C4
1,C42,C43,C44,C45,C
46,C47,C48,C51,C52,
C53,C54,C76,C87,C9
8
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C63,C64 0CH2A-0019A
68N F, 50 Volt, K PER, X7R(JB), 1608
R/TP, T=0.9(MAX)
C161,C164,C166,C17
0,C62,C68,C69,C78,C
79,C80,C81,C83
0CH2A-0026A
10U F, 25 Volt, K PER, X5R(JB), 3225
R/TP, T=1.0(MAX)
C6,C9 0CH2A-0068A
10 Volt, X7R(JB), K %, 1005 R/TP, 0.1U F,
T=0.55 MAX
C30 0CH5681K412 680PF 50V J NP0 1608 R/TP
D1,D2,D3 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0061A SDZ6V2D, AUK, SOD-323, R/TP
D4 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FSLO-0012A
F0603HI2500V032TM, AEM,
Cupper/Nickel, 32V, 2.5A, UL,
1.6X0.8X0.95 (MM), R/TP
U3 0IDIL-0002A
AP7167-FNG-7, DIODES, ADJUST_3.3V,
1.2A, DFN3030-10, R/TP, 10
UC1 0IEDL-0008A
LG5901-ED, EDTECH, LVDS, 6/8, 2,
MINI-LVDS, 6, 1, DRD, GIP, AFRC, DGA,
ODIN3, MLF, TR, 68
U2 0ISKL-0001A
S-24CL04A0I-T8T1GE, SEIKO
INSTRUMENTS, 4k, 4ms (typ), TSSOP,
R/TP, 8
US1 0ISML-0002A
SM4005, Silicon Mitus, TN MNT,
Boost+Op-Amp+L/S+D/C+PVcom, QFN
(7x7), R/TP, 48 pin
L1 0LCAA-0069B
TNI8016-100M, DACOWELL, 10UH,
M=20%, 2.1A, 0.093, 8.0X11.0X1.8 (1.2MM,
IN-BOARD), R/TP
R10,R107,R132,R133,
R136,R142,R17,R177,
R180,R181,R182,R18
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
