24
4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz)
- 950 1235 mA 1,5
I
LCD-BLACK
(60Hz) - 1155 1500 mA 2,5
I
LCD-BLACK
(75Hz)
- 1800 mA 5
Power Consumption P
LCD
- 4.75 6.18 Watt 1
Inrush current I
RUSH
- - 3.0 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 110 120 mA 2,7
LED String Voltage Vs 42.0 44.8 47.6 V 3,7
Power Consumption PBar - 9.9 10.5 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7
