AOC e2260Sd Service Manual

47
Q52G100204500A00HB
AL FOIL
Q52G100204500A00HB
AL FOIL
Q52G100204500A00HB
AL FOIL
Q52G1301024A0100YY
BIG CARTON TAPE FOR AOC 60MM
Q52G1801MNT119AFJY
INSULATING SHEET
Q52G6019 14
TAPE
ECN403
S95G179T30PW21
FFC CABLE 30P 245mm 1.0MM
H40G000261553A
TCO'05 EPA LABEL
756GHCCB0BV0070001
MAIN BOARD-CBPCCUFA1H2
SMTCC-U402
100GAMSC001W11
MCU ASSY-056G2233501
CN404
033G3802 6B Y L
WAFER
CN701
033G3802 9B Y L
CONN 2.0 9P
CN410
033G801930F CH JS
FFC CONN 1.0mm 30P R/A 34mm 6.3mm
CN101
088G 35315F XH
D-SUB 15PIN VERTICAL CONN WITH SCREW
CN102
088G 35424FXNH
DVI CONN WITH SCREW 24P R/A
X401
093G 22 53CEC
CRYSTAL S-F-14.31818M-32-3030-2085-30
709G52700HM001
COMSUMPTIVE ASSY
H40G 45762429A
LABEL
LED001
381G00122YG0GP
LED yellow/green GP32032M/P310-ZY-30
CN001
395G820H06DM04
HARNESS 6P-6P 320mm
709G53570HM001
COMSUMPTIVE ASSY
GND2
009G6005 1
GND TERMINAL
GND1
009G6005 1
GND TERMINAL
IC902
056G 139 3A
PC123Y22FZOF SHARP
NR901
061G 58809MEN
RST NTCR 8OHM +/20%/NMM01 4A XIANZHENG
C908
063G107K474 6S
0.47UF +-10%
C907
067G 40Z12115H2010
EC 120uF 20% 450V 20*40mm
L906
073G 253 91 H
IND CHOKE 3.5uH+-10% DADONG
L905
073G 253 91 H
IND CHOKE 3.5uH+-10% DADONG
L801
073G 253214 DN
CHOKE COIL 47UH 10% LZ.CC013.G01 2.5A
L901A
073L 174 26H1G
LINE FILTER 27MH MIN UU16
T901
080GL22T 3 N3
X'FMR 490UH 7% 4UH YUVA-1656
CN901
087G 501 32 S
AC SOCKET ST-01CP-BCE-R
BD901
093G 50460 50
BRIDGE GBL08 4A/800V GBL
D801
393G0060A0300S
SCHOTTKY SR3100-MK18 3A 100V DO-201AD
CN902
395G082510T549
HARNESS 10P(SCN)-9P(2008) 120mm
CN801
395G820H06T508
HARNESS 6P(SANW)-6P(CI1406) 320mm
705GHB57009
Q901 ASS'Y
705GHB93007
D901/D905/D906 ASS'Y
709G53610HM001
COMSUMPTIVE ASSY
