16
5. Block Diagram
5.1 Main Board
715G7778M0B000004F
FLASH MEMORY
MX25L4006EM1I-12G
4Mb
(U402)
Scalar RTD2483BR-CG
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(CN401)
D-Sub
Connector
(CN101)
Crystal 14.31818M
(X401)
Key Control
Interface
(CN403)
HDMI
Connector
(CN501)
PHONE JACK
Connector
(CN601)
