AOC E2270SWHN User Manual

47
EPEAT Declaration（Optional）
EPEAT is a system to help purchasers in the public and private sectors evaluate, compare and select desktop
computers, notebooks and monitors based on their environmental attributes. EPEAT also provides a clear and
consistent set of performance criteria for the design of products, and provides an opportunity for manufacturers to
secure market recognition for efforts to reduce the environmental impact of its products.
AOC believes in protecting the environment.
With a key concern for the conservation of natural resources, as well as landfill protection, AOC announces the
launch of AOC monitor’s packaging recycling program. This program is designed to help you discard of your
monitor carton and filler materials properly. If a local recycling center is not available, AOC will recycle the
packaging material for you, including foam filler and carton. AOC Display solution will only recycle AOC monitor
packaging. Please refer to the following website address:
Only for North and South American, excluding Brazil:
http://us.aoc.com/about/environmental_impact
For Germany:
http://www.aoc-europe.com/en/service/tco.php
For Brazil:
http://www.aoc.com.br/2007/php/index.php?req=pagina&pgn_id=134

AOC E2270SWHN Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	108 MHz
Display diagonal	21.5 \
Surface hardness	3H
Display technology	-
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Viewable size, vertical	268.11 mm
Viewing angle, vertical	65 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	700:1
Display number of colors	16.7 million colors
Display brightness (peak)	- cd/m²
Display diagonal (metric)	54.61 cm
Viewable size, horizontal	476.64 mm
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	True
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
HDMI version	1.4
DisplayPorts quantity	0
Headphone connectivity	3.5 mm
Package type	Box
Package depth	108 mm
Package width	558 mm
Package height	394 mm
Package weight	3450 g
VGA cable length	1.2 m
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Height (with stand)	375 mm
Weight (with stand)	2700 g
Depth (without stand)	48 mm
Width (without stand)	503.37 mm
Height (without stand)	311.1 mm
Weight (without stand)	- g
