AOC E2343F2 Series Service Manual

45
0ILUL-0167A
LS0608M2-C4TS, LUSEM, 720, 6BIT,
MINI, C_B, R/TP, 35MM, 4PF, UPILEX, T8
2
nd
source
6871L-2341A Source, Single, LM230WF5-TRA2-7F1-A0
C1,C2,C5,C6,C7,C8 0CH2104H942 0.1uF, Z, 25V, Y5V, 0.9mm, 1608, R/TP
C70 0CH2153K562 15nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C44,C50,C51,C53,C71 0CH2473K562 47NF 50V K X7R 1608 R/TP
C12 0CH2474D572 0.47uF, K, 10V, X5R, 0.95mm, 1608, R/TP
C41 0CH2A-0006A
4.7U F, 16 Volt, K PER, X5R(JB),
3216 R/TP, T=1.0(MAX)
C204,C3,C4,C77 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB),
1608 R/TP, T=0.9(MAX)
C43,C52 0CH2A-0010A 33nF, M, 25V, X7R, 0.9mm, 1608, R/TP
C32,C33,C73,C74 0CH2A-0011A
10U F, 16 Volt, K PER, X5R(JB),
3216 R/TP, T=0.95(MAX)
C101,C102,C103,C104,
C105,C106,C107,C108,
C109,C110,C111,C112,
C113,C114,C301,C303,
C305,C307,C31,C42,
C85,C904
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C76 0CH2A-0017A
2.2U F, 10 Volt, K PER, X5R(JB),
1608 R/TP, T=0.9(MAX)
C55,C56,C61,C62,
C64,C66
0CH2A-0026A
10U F, 25 Volt, K PER, X5R(JB),
3225 R/TP, T=1.0(MAX)
C901,C902 0CH5680K412 68PF, J, 50V, 1608, R/TP, 0.9mm
C23 0CH5681K412 680PF 50V J NP0 1608 R/TP
C801 0CH5820K412 82PF 50V J NP0 1608 R/TP
D3,D4,D5 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0065A SDZ5V1D, AUK, SOD-323, R/TP
D6 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FFST-0009A
F0603FA3000V032TM, AEM, Ceramic,
32V, 3A, UL/CSA, 1.6X0.8X0.8mm, R/TP
U6 0IDIL-0002A
AP7167-FNG-7, DIODES, ADJUST_3.3V,
1.2A, DFN3030-10, R/TP, 10
UC1 0ILDL-0001A
LDA5001A, LGD, LVDS, 6/8, 1/2,MINI-LVDS, 6,
1, DRD, GIP, AFRC, DGA, ODIN2, MLF, TR, 68
U4 0ISGL-0008C
M24C04-RDW, STmicroeletronics,
4K, 5ms, TSSOP, R/TP, 8
US2 0ISML-0002A
SM4005, Silicon Mitus, TN MNT,
Boost+Op-Amp+L/S+D/C+PVcom,
QFN (7x7), R/TP, 48 pin
