AOC E2343F2 Series Service Manual

46
L1 0LCAA-0069A
TNI8016-100M, DACOWELL, 10UH,
M20, 2.1A, 0.093, 8.0X11.0X1.8
(1.2MM,IN-BOARD), R/TP
R203,R205,R215,R216,
R225,R226,R300,R303,
R307,R308,R35,R362,
R41,R42,R51,R6,R7,
R802,R803,R806,R808,
R83,R9
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R28 0RH0102C422 10 OHM 1/16W 1608 1% D R/TP
R901,R903 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R211,R212,R213,R214,
R44,R45,R46,R47
0RH0302C422 30 OHM 1/16W 1608 1% D R/TP
R221,R222,R223,R224 0RH0562C422 56 OHM 1/16W 1608 1% D R/TP
R11,R12 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R13,R140 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R111,R112,R120,
R3,R5
0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R910 0RH1003C422 100K OHM 1/16W 1608 1% D R/TP
R117 0RH1102C422 11K OHM 1/16W 1608 1% D R/TP
R116,R121,R122 0RH1202C422 12K OHM 1/16W 1608 1% D R/TP
R64 0RH1300C422 130 OHM 1/16W 1608 1% D R/TP
R807 0RH1500C422 150 OHM 1/16W 1608 1% D R/TP
R103 0RH1501C422 1.5K OHM 1/16W 1608 1% D R/TP
R1,R126,R906 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R106 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R110,R909 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R130 0RH1801C422 1.8K OHM 1/16W 1608 1% D R/TP
R14,R81 0RH2001C422 2K OHM 1/16W 1608 1% D R/TP
R114,R127,R132 0RH2002C422 20K OHM 1/16W 1608 1% D R/TP
R131,R182,R72 0RH2202C422 22K OHM 1/16W 1608 1% D R/TP
R10,R8,R82 0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R105,R202 0RH2702C422 27K OHM 1/16W 1608 1% D R/TP
R15 0RH3001C422 3K OHM 1/16W 1608 1% D R/TP
R115,R2 0RH3002C422 30K OHM 1/16W 1608 1% D R/TP
R129 0RH3301C422 3.3K OHM 1/16W 1608 1% D R/TP
R201 0RH3902C422 39K OHM 1/16W 1608 1% D R/TP
R63 0RH4300C422 430 OHM 1/16W 1608 1% D R/TP
R125 0RH4701C422 4.7K OHM 1/16W 1608 1% D R/TP
R104 0RH4702C422 47K OHM 1/16W 1608 1% D R/TP
R43,R60,R62,R908 0RH5101C422 5.1K OHM 1/16W 1608 1% D R/TP
