AOC E2343F2 Series Service Manual

48
756GQACB-AA269--00 MAIN BOARD-CBPCANZA2QQ
SMTCA-U402 100GANGD006YT1 MCU ASS'Y-056G2233501
801GQAEE282 L23W-TB1-tbp1 E2343FW2 LTD ASS'Y
0M1G-140--6125 SCREW
0M1G-140--8125 SCREW
0M1G-940--5125 .CREW
0M1G1730--6120 SCREW,42-D020523
0Q1G-140-10120 SCREW
A37G0188012 HINGE 21.5
A85G0260201 SHIELD
A85G0272201 shield cover
803GQA44130 L23W-TB1-tbp1 E2343FW2 EPS ASS'Y
Q44GD089101 CUSHION EPS
Q44GD089201 CUSHION EPS
A15G1327101 Tilt Support Bracket
A33G1151AGS-1B0100 lens
A34G2041AKMA1M0100 BASE COVER-TOP
A34G2042AED-3B0100 BASE TRIM
A34G2043AGS-1B0100 HINGE FRONT COVER
A34G2044AGS-1B0100 HINGE BACK COVER
A34G2097AEDK1B0130 BEZEL L23W-TB1-tbp1
A34G2142AGSA1B0100 REAR COVER L23W-TB1-tbp1
ADPC91236YJ1 ADAPTER BOARD
CN401 033G3802-7B--Y---L conn 2.0 7p
033G3802-7B--Y CONNECTOR 7P 2.0 DIP 2
nd
source
040G-45762412B CBPC LABEL
C718 067G204V181-3K CS CAP 180uF 16V 8*8 mm
067G204V181-3C CS CAP 180uF M 16V 8*8 mm
C716 067G204V471-2K CS CAP 470uF 10V 8*8 mm
067G204V471-2L CS CAP 470uF
C807 067G415R479-9K EC 4.7UF 20% 100V ED 8*12
067G415R479-9L EC 4.7UF 20% 100V RZW 8*12
FB701 071G--5526A--H CORE 6.0X3.5X3.5 127 25% 3.5X6.0
071G--55-26--S FERRITE CORE
CN603 088G-30232C PHONE JACK 3.5mm BLACK 5PIN
088G-302-32-YG HONE JACK 3.5mm 5P? BLACK 2
nd
source
CN701 088G-3041CF DC JACK
088G-3041YG DC POWER JACK 3P - - 2
nd
source
CN101 088G-35315F-HD D-SUB CONN F ATTACHED SCREW
088G-35315F-XH D-SUB 15PIN VERTICAL CONN WITH SCREW 2
nd
source
