AOC E2343F2 Series Service Manual

49
U401 090G6077--2-----GP HEAT SINK
CN409 311GW200C30AAL WAFER 2.0MM 2*15P
033G804330C-HR Wafer 2*15P 2.0picth 2
nd
source
U401 056G-562392 SCALER NT68677UMFG/E QFP-128
U704 056G-563113 IC G1117-18T63Uf 1A/1.8V SOT-223
U705 056G-563215 IC DC/DC MP1584EN SOIC8E
U702 056G-563512 IC G1117-33T43UF TO-252
056G-563204 IC G960T43Uf TO-252
U503,U504,U506,U507 056G-662-35 ESD PROTECT TVU1240R1A N/A
056G-662-18 IC AZ1045-04F.R7G DFN2510P10E
U101,U103,U502,U505 056G-662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS
056G-662-13 IC AZC099-04S SOT23-6L
U801 056G-700--5 IC LED driver MP3389EF TSSOP28
U102,U501,U508 056G1133531 EEPROM FM24C02A-SO-T-G 2K SOP-8
056G1133541 EEPROM RM24C02-H0-B-R 2K SOP-8
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8
056G2233-11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M
U601 056T-616516 IC APA2176AQBITRL TQFN3X3-16
Q402 057G-417517
Tra LMBT3906LT1G -200mA/-40V SOT-23
LRC
057G-417526 SMALLTRAN MMBT3906 -0.2A -40V SOT-23
Q302,Q701 057G-417518
TRA LMBT3904LT1G 200mA/40V SOT-23
LRC
057G-417525 SMALLTRAN MMBT3904 200mA 40V SOT-23
Q301 057G-763527 FET APM2303A -30V/-4.3A SOT-23 ANPEC
057G-763513 P6403FMG BY NIKO-SEM
Q806 057G-763947 MOSFET APM8005KCTRG SOP-8
057G-763-92 FET P8008HV 4A/80V SOP-8
R425,R432,R442,R501,
R502,R503,R504,R505,
R506,R507,R509,R510,
R518,R519,R520,R521,
R522,R523,R524,R526,
R527
061G0402000-JI
TEST ONLY RST 0402 0.05R MAX 1/16W
TA-I
061G0402000-JT RST CHIPR MAX0R05 1/16W TZAI YUAN
R102,R103,R104 061G0402100-JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
061G0402100-JT RST CHIP 10R 1/16W 5% TZAI YUAN
