AOC E2343F2 Series Service Manual

53
065G060322232K---Y CAP CHIP 0603 2N2 50V X7R /-10%
C607,C610 065G060322515K---T CAP CHIP 0603 2.2uF K 16V X5R
065G060322515K---M MLCC 0603 2.2uF 10% 16V X5R
C801 065G060347412K---A CAP CHIP 0603 470nF K 16V X7R
065G060347412K---Y CAP CHIP 0603 0.47UF K 16V X7R
C802 065G060368332K---A CAP CHIP 0603 68NF K 50V X7R
065G060368332K---Y CAP CHIP 0603 68NF K 50V X7R
C815 065G080510131J---F CAP CHIP 0805 100PF J 50V NPO
065G080510131J---Y CAP CHIP 0805 100PF J 50V NPO
C720 065G080510615K---T CHIP 10uF 16V X5R 0805
065G080510615K---M CAP CHIP 0805 10uF K 16V X5R
C402,C405,C412,C414,
C416,C419,C420,C425,
C436,C608,C723
065G0805106A5K---T CHIP 10uF 10V X5R 0805
065G0805106A5K---3 CHIP 10uF 10V X5R 10%
C803,C804 065G080547432K---A CAP CHIP 0805 0.47UF K 50V X7R
065G080547432K---Y CAP CHIP 0805 470N 50V X7R /-10%
C302,C704,C707 065G1206226A5K---T CAP CHIP1206 22uF K 10V X5R
065G1206226A5K---M CAP CHIP 1206 22UF K 10V X5R
U402 070GHDCP500HDC HDCP CODE
FB104,FB301,FB401,
FB402,FB403,FB404,
FB405,FB406,FB407,
FB408,FB410,FB604
071G-56K121--M CHIP BEAD
071G-56K121 CHIP BEAD
FB602,FB603 071G-59C600
CHIP BEAD 60 OHM 0603
FCM1608CF-600T06
071G-59C600--M CHIP BEAD 60 OHM 0603 600mA
FB101,FB102,FB103 071G-59K190-TA
CHIP BEAD 19 OHM 500mA
FCB1608KF-190T05
L801 073G253S-98-DN SMD CHOKE 47uH 20% 3A 64R
073G253S-98--X
SMD CHOKE 47UH 20% 0.064R
3SMSL12575-470
L701 073G253S521--H SMD CHOKE 22UH 20% 3.3A HF
073G253S521--M SMD CHOKE
CN501,CN502 088G-34019G-AV DMI HEADER 19P
088G-34019G-AD HDMI HEADER 19P - - 2
nd
source
088G-34019G-AT HDMI HEADER 19P - - 2
nd
source
D501,D502 093G--60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23
D101 093G--64-42--L DIODE LBAV70LT1G SOT-23 LRC
X401 093G-22S-51--A CRYSTAL 12MHZ 32P SMD-49
