AOC E2343F2 Series Service Manual

54
ZD101,ZD501,ZD503 093G-39S-24--T RLZ 5.6B LLDS
D801 093G-60S907--T DIODE 3A/100V B3100B SMB
D701,D703,D704,D707,
D708
093G3004--3 SM340A
CN803 311GF050B10ADH FFC CONN 0.5MM 10P
033G801910Y--H FPC CONN. 0.5mm SMT 10P 2
nd
source
715G4604M0C000004I MAIN PCB FR4 DS 146x115*1.6 6
F40G0003615-1A e43Fw2-E943f2 POP LABEL
KEPCAQQR KEY BOARD
CN001 033G8032-7F--S--HR CONNECTOR 7P 1.25
U001 056G-669-15 Test Only IT7230BFN
R005,R006 061G0402000-JT RST CHIPR MAX0R05 1/16W TZAI YUAN
061G0402000-JY RST CHIPR 0 OHM -5% 1/16W YAGEO
R004 061G0402101-JT RST CHIP 100R 1/16W 5% TZAI YUAN
061G0402101-JY RST CHIPR 100 OHM -5% 1/16W YAGEO
R001,R002,R003 061G0402103-JT RST CHIP 10K 1/16W 5% TZAI YUAN
061G0402103-JY RST CHIPR 10KOHM -5% 1/16W YAGEO
R007,R008,R009,R010,
R011,R012
061G0402472-JT RST CHIP 4K7 1/16W 5% TZAI YUAN
061G0402472-JY RST CHIPR 4.7KOHM -5% 1/16W YAGEO
C008 065G040210131J---Y CAP CHIP 0402 100P 50V NPO +/-5%
065G040210131J---T CAP CHIP 0402 100PF 50V NPO
C005,C006,C007 065G040210427Z---T CAP CHIP 0402 0.1UF 25V Y5V
C011,C013 065G0402105A7Z---A CAP CHIP 0402 1uF 10V Y5V
065G0402105A7Z---Y CAP CHIP 0402 1uF Z 10V Y5V
065G0402105A7Z---3 CAP CHIP 0402 1uF Z 10V Y5V
C003,C004 065G040212031J---Y CAP CHIP 0402 12P 50V NPO +/-5%
065G040212031J---T CAP CHIP 0402 12PF 50V J NPO
LED001 081G--15--2-EL LED WHITE/RED 12-22/T7R8D-D30/2C SMD
LED002,LED003,
LED004,LED005
081G-15W--1-EL CHIP LED WHITE
709G4164-QS001 COMSUPTIVE ASS'Y
E715 715G4164K01000004F KEY PCB FR4 DS97X23X1.0MM
715G4164K01000004M KEY PCB FR4 DS97X23X1.0MM 2
nd
source
Q05G6131--1 WASHER
Q36G-600517 duster cloth
Q40G-18E61515A RATING LABEL
Q40G000161515A CARTON LABEL
Q40G000361596A POP LABEL(win 7+EPEAT+EPA)
Q40G0003615B81 LABEL warning e43 ww
