AOC e2351Fh Service Manual

4
1. Monitor Specifications
Panel
Model number e2351Fh
Driving system TFT Color LCD
Viewable Image Size 584.2mm diagoanl
Pixel pitch 0.0883*RGB mm(H) x 0.265mm(V)
Video R, G, B Analog lnterface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 144MHz
Resolution
Horizontal scan range 64 kHz – 83 kHz
Horizontal scan Size(Maximum) 535.7mm
Vertical scan range 50 Hz - 76 Hz
Vertical scan Size(Maximum) 311.2 mm
Optimal preset resolution 1920x1080 (60 Hz)
Highest preset resolution 1920x1080 (60 Hz)
Plug & Play VESA DDC2B
Input Connector VGA/DVI/HDMI
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, Positive
Power Source 100~240VAC, 50/60Hz
Power Consumption
36W
Standby < 0.5 W
Physical
Characteristics
Connector Type VGA/DVI/HDMI
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base) 425.5mm
Width 550mm
Depth 194mm
Weight (monitor only) 2.478kg
Environmental
Temperature:
Operating 0°Cto 40° C
Non-Operating -25°Cto 55°C
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
Altitude:
Operating 0~ 3,658m (0~ 12,000 ft )
Non-Operating 0~ 12,192m (0~ 40,000 ft )
